ZEBRA Thermal Barcode Label Printer ZD220

This 4-inch printer prints receipts or labels quickly, at 4 in. per second, to keep your workflows moving. Increased memory allows you to store more fonts and graphics. A single LED indicator and single button for feed/pause make it easy to operate and identify printer status. Choose from direct thermal or thermal transfer models, and add an optional factory-installed peeler. The ZD220 features Print DNA™ Basic, a core set of software applications and capabilities to deliver a cost-effective and dependable print experience. The ZD220 is simple to install and begin printing - right out of the box. USB connectivity allows for universal interoperability. Easily replace legacy printers using ZPL, EPL or non-Zebra command languages. And, media changes are expedited with Zebra’s OpenACCESS™ clamshell design. It is ideal for use in transportation and logistics, light manufacturing, retail and healthcare applications to print a variety of tickets, tags, passes, labels and receipts.

Quick features

• Direct thermal printing
• ZPL and EPL programming languages
• Single LED status indicator
• Single button for feed/pause
• USB connectivity
• OpenACCESS™ for easy media loading
• Dual-wall frame construction
• ENERGY STAR qualified
• Suitable for printing receipts, labels, 1D and 2D barcodes, wristbands

Thermal printer specifications

• Print Method: Direct Thermal Line Printing
• Print Speed: 102 mm/sec
• Interface: USB
• Dimensions: 267 mm L x 197 mm W x 191 mm H
• Resolution: 203 dpi
• Memory: 128 MB

• Max. print width: 4.09 inch / 104 mm
• Media types: Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
• Max. roll diameter: 5 inch / 127 mm
• Max. roll width: 1.33 inch / 33.8 mm upto 4.3 inch / 110 mm
• Ribbon core size: 0.5 inch / 127 mm
• Fonts and symbologies: Barcode 2:1, Barcode 3:1, Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code, Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec. 16 resident expandable ZPL II bitmap fonts, Two resident scalable ZPL fonts, Five resident expandable EPL2 fonts, Native open-type font support
