FORTUNER FR3200, 3.2KVA, 3200VA, 1-Phase, Wifi, Wall Mount Solar Inverter With LCD Screen, 24VDC

FEATURES

• Pure sine wave solar inverter (off grid)

• Wifi and GPS available for IOS and Android

• Compatible with Li battery
• Built-in 80a MPPT solar charger

• High PV input voltage range (30-400vdc)
• Built-in anti dust kit for harsh environments
• Smart battery charge design to optimize battery life
• Solar energy is provided directly to the load first

SPECS

• Phase: 1-single phase
• Rated output power: 3200va/ 3000w

Battery and charger

• Battery voltage: 24vdc
• Floating charge voltage: 27vdc
• Overcharge protection: 33vdc

AC input

• Voltage: 230vac
• Selectable voltage range: 170-280vac (for Personal computers), 90-280vac (for home appliances)
• Frequency range: 50Hz/ 60Hz (auto sensing)

AC output

• AC voltage regulation: 230vac +-5%
• Surge power: 6400va
• Efficiency PV to Inverter: 98%
• Efficiency Battery to Inverter: 94%
• Transfer time: 10ms (for personal computers), 20ms (for home appliances)

Solar charger and AC charger

• Solar charger type: MPPT
• Max. PV array power: 3000w
• MPPT range at operating voltage: 30-400vdc
• Max. input current: 1/ 13a
• Max. solar charging current: 80a
• Max. AC charging current: 60a
• Max. solar +AC charging current: 80a

GENERAL SPECS

• Dimensions (D x W x H): 357 x 273 x 95mm
• Net weight: 4.8kg
• Communications port interface: RS232, Wi-fi, GPRS
• Operating temperature: -10-50 degrees C
• Batteries: NOT INCLUDED, must be bought separately as per requirement. Click here to see battery options that we offer
